Yaesu FTA-250L

The New FTA-250L Ultra-Compact and Rugged Construction “Comm Only” Air Band Transceiver.

The new FTA-250L is an ultra-compact (W52 x H105 x D30mm) and competitively priced COMM ONLY transceiver.

The new FTA-250L includes all basic features and functions which many operators need for the airband AM communication.

The new FTA-250L provides 5W TX output power and has easy-to-operate menu with Dot MatrixLCD.
The Loud 700mW internal audio speaker guarantees calls will not be missed. 8.33kHz Narrow
Band compatible, and with 250 programmable channels with up to 7 alphanumeric characters, all
favourite channels can be easily stored and retrieved with just a few button presses. Flip-flop key
equipped on left side of radio is easy-to-use for last channel recall up to 9 channels.

RADIO FEATURES:
• 5 Watts TX Output Power (Air Band: AM 5W P.E.P., 1.5W carrier)
• Compact Design, Measuring W2.1″ x H4.1″ x D1.2″ (52 x 105 x 30 mm)
• Loud Audio (700 mW)
• 8.33 kHz Narrow Band Compatible
• Noise-Cancelling Function for both Transmit and Receive Audio
• 250 Memory Channels
• Includes High-Capacity Rechargeable Li-ion Battery Pack (7.4 V 1950 mAh)
• External-DC input for Operation and Charging
• AF Pitch Control
• Flip Flop Last Channel Recall
• Dual Watch
• Back-lit Keypad and Display with Dimmer
• PC Programmable (Requires Optional USB Cable: SCU-37)

SPECIFICATIONS:
RX Frequency Ranges: 118.000 to 136.975 MHz
161.650 to 163.275 MHz (Weather Channels)*
TX Frequency Ranges: 118.000 to 136.975 MHz
Channel Spacing: 25 kHz/8.33 kHz
TX Emission Type: AM
RX Emission Type: AM&FM (FM: for Receiving the Weather Channels)*
RF Power Output: 5.0 W (PEP), 1.5 W (Carrier Power)
Case Size (W x H x D): 52 x 105 x 30 mm w/o Knob&Antenna
Weight: 300 g w/ SBR-25LI, Antenna and Belt Clip
Qty in Master Carton: 10
Warranty: 3 Years
* Only available in NOAA weather service areas

SUPPLIED ACCESSORIES:
• Antenna
• Belt Clip (SHB-18)
• Li-ion Battery Pack (SBR-25LI 7.4V, 1950 mAh)
• Charger Cradle (SBH-22)
• Cigarette Lighter DC/DC Converter (SDD-12)
• Headset Adapter Cable (SCU-15)
• Operating Manual
• Warranty Card
• AC Adapter (SAD-20)

Comes with NZ power plug converter

Yaesu FTA-450

The YAESU FTA-450L is a competitively priced (COMM ONLY) version of the wildly successful FTA-550L and FTA-750L. Featuring the same Easy To Operate icon driven menu system, on a large 1.7" x 1.7" Full Dot Matrix Display.

The same Loud 800mW internal audio speaker guarantees calls will not be missed. 8.33 kHz Narrow Band compatible, with a programmable 200 channel memory bank, means all favorite channels can be easily stored and retreived with just a few button presses. Valued packaged with all the necessary accessories, including 110VAC and 12VDC chargers, headset adapter, Alkaline battery tray, Belt Clip, USB programming cable, and a large capacity 1800mAh Li-Ion rechargeable battery.

5 Watts TX Output Power (Air Band: AM 5W P.E.P. typ, 1.5W carrier)
Huge 1.7" x 1.7" (43.2 x 43.2 mm ) Full-Dot Matrix Display (160 x 160 dots)
800 mW Loud Audio Output
8.33 kHz Narrow Band compatible
200 Memory Channels with 15 Alphanumeric Characters
Water Protection - IPX5 Rating
Includes High-Capacity Rechargeable Li-ion Battery Pack (7.4V 1,800 mAh)
Includes Alkaline Battery Tray (6 x AA)
NOAA Weather Channel Receive
NOAA Weather Alert Function
The channel configurations can be easily re-programmed using the PC Programming Software

Frequency Ranges: RX 118.000 to 136.975 MHz Warranty: 3 Years

INCLUDES

New Zealand plug converter

Li-Ion Battery Pack (SBR-12LI 7.4V, 1800 mAh)

Charger Cradle (SBH-11) AC Charger (SAD-11)
Cigarette Lighter DC/DC Converter (SDD-12)
Antenna (SRA-13A )
Belt Clip (SHB-11)
Headset Adapter Cable (SCU-15)
Alkaline Battery Tray (SBT-12 6 x AA)
USB Cable (T9101606)
Operating Manual
Warranty Card
